DT1500HD

DT1500HD

型号: DT1500HD
电源: 380V/3PH/50HZ, 460-480V/3PH/60HZ
输入功率: 43.6KW
额定电流: 88.0A
制热量: 88KW
制冷量: 70KW
除湿量: 120L/H
制冷剂: R134A/20.0KG
风量: 120000-153000m³/H
主机尺寸: 2250*1360*1590mm
烘干房尺寸: 11860mm*3230mm*2200mm
烘干量: 4000KG/batch
保修期: 1 Years

Product DisplaySpecificationDownload

Model

Power supply

Power input(KW)

Rated current

Refrigerant

(R134/KG)

Heating capacity(KW)

Cooling capacity(KW)

Dehumidify capacity(L/H)

Hot air flow(m³/H)

Dryer size(mm)

Drying chamber size(mm)

DT300H

220V,1PH,50/60HZ

5.5

25.0A

2.5

10.5

7.8

12.0

23600-12800

1650*856*1280

3800*2190*2200

380V,3PH,50/60HZ

5.5

11.0 A

2.5

10.5

7.8

12.0

23600-12800

1650*856*1280

3800*2190*2200

DT500H

380V/3PH/50HZ

460-480V/3PH/60HZ

6.9

14.0 A

3.8

16.0

12.5

20.0

23600-12800

1650*856*1280

3800*2190*2200

DT600H

9.5

19.0 A

4.0

21.0

18.0

25.0

47200-25600

1650*1056*1280

6150*2190*2200

DT1200H

19.4

39.0 A

8.0

42.0

32.0

50.0

70800-38400

2089*1260*1580

6350*3230*2200

DT1500H

21.8

44.0A

9.0

50.0

40.0

60.0

76500-54000

2089*1260*1580

6350*4670*2200

DT300HD

11.0

22.0 A

5.0

21.0

15.6

24.0

47200-25600

1650*856*1280

7050*2190*2200

DT500HD

13.8

28.0 A

7.6

32.0

25.0

40.0

47200-25600

1650*856*1280

7050*2190*2200

DT600HD

19.8

37.0 A

8.0

42.0

36.0

50.0

47200-25600

1650*1056*1280

10100*2190*2200

DT1200HD

32.8

66.0 A

16.0

84.0

64.0

100.0

70800-38400

2089*1260*1580

10750*3230*2200

40.0

80.0 A

16.0

84.0

64.0

100.0

120000-72000

2089*1260*1580

10750*3230*2200

DT1500HD

43.6

88.0A

18.0

100.0

80.0

120.0

153000-120000

2089*1260*1580

12900*4670*2200


What is a heat pump dryer?
A heat pump dryer is a type of condenser dryer. These dryers are extraordinarily energy efficient, as they recycle heat in the process of extracting moisture – often resulting in energy efficiency ratings of up to 4.0(COP)


Thanks to their gentle, highly-efficient drying action, heat pump dryers have been a popular eco-friendly option in China, South East Asia, India,South America and Africa, even if Europe and the US for many years.


How a heat pump dryer works
A heat pump dryer passes hot air over your products(fruits/vegetabl/meat/fish/herbs...etc.) to collect moisture and dry them. This same air then goes through air to air heat exchanger and an evaporator, where the moisture is condensed and collected in a water tank or discharge to outdoor.


Where other dryers simply blow hot air on your poducts, heat pump dryers use a more sophisticated energy-efficient heat exchange system to conserve and reuse the same air (waste heat recovery).


Benefits of a heat pump dryer (and why they’re such a good idea)
Heat pump dryers have significant advantages over cheaper dryers. You may spend a little more initially on a heat pump dryer, but their many benefits far outweigh the early outlay.


Super efficiency
Thanks to their reheating and recycling process, heat pump dryers are about as energy-efficient as it gets, with most models scoring the maximum energy saving rating. So you’re saving yourself a lot of money – more than half the energy use of vented electric dryers of most manufacturers.


They’re much cheaper to running
A heat pump dryer will provide you with significant short- and long-term savings on money and time. In fact, they’re so energy-efficient that you’ll feel very comfortable using them on a daily basis.


Usually, heat pump dryer only use approximately 35% of the energy used by conventional dryers.


Heat pump drying is much gentler on products
As their drying air temperature is considerably lower than conventional dryers, heat pumps are less abrasive on your product. They feature multiple sensors to detect moisture, so your products are dried more consistently and treated with better care. Low temperature drying of specialty crops reduces the risk of loss in nutrient content and damage to physical properties. Drying system incorporating a dehumidification cycle have been developed that both conserve energy and handle the material gently. The dryer operates using a heat pump where both sensible and latent heats are recovered from the exhaust air. The heat is then recycled back through the dryer by heating the air entering the dryer.




Convenient


A heat pump dryer’s remarkable energy efficiency means you can feel comfortable using it at any time. we can manufacture small or big model heat pump dryers for different request customers.



Heat pump dryers can be use in anywhere:
we can do open loop + close loop type dryers for warm area, and close loop type dryers for cold area.
Heat pump dryers suitable for drying many products from fruit,vegetable meat to meat fish etc...And it’s all thanks to their great design.
